| Brand Name: | Lontl |
| MOQ: | 12 sets |
| Payment Terms: | L/C, T/T |
Prefab Folding Container Houses, also known as foldable or collapsible container houses, are modular structures that can be easily transported and assembled. They are constructed using shipping containers that are designed to fold or collapse for efficient storage and transportation. Here is some information about prefab Folding Container Houses.
Why choose container house to be your dream house ?
1.. it is a turn-key house .
This kind container house can be designed just as one unite or a whole from several containers ,than by simple connection such as by bolts. We will prefabricated the insulation , doors, windows, inndecation , water piping , electricity wiring , sockets, switches, lights , kitchen , bathroom, heating & cooling , furniture etc. It is nearly a turn-key house , save your time and energy.
2.. It can withstand earthquake .
Since the container house aren't built by bricks , they aren't falling during earthquake, so it can keep you safe during earthquake .
The Specification of Our Folding Container House:
|
Basic Characteristics |
External dimensions(mm) | 5800L*2440W*2500H | |
| Internal dimension(mm) | 5640L*2320W*2400H | ||
| Folded state (mm) | 5800*2440*400 | ||
| Total mass (kg) | 1100 | ||
|
Frame Structure |
Top girder | Q235B Rectangular square tube 60*80*1.3mm | |
| Bottom girder | Q235B Rectangular square tube 80*140*1.5mm | ||
| Front and rear main beam | Q235B Rectangular square tube 80*80*1.3mm | ||
| Side wall frame | Q235B Rectangular square tube 40*80*1.3mm | ||
| Bottom load-bearing | Q235B Rectangular square tube 40*40*1.3mm | ||
| Top load-bearing | Q235B Rectangular square tube 40*40*1.3mm | ||
| Hanging head | Q235B 125*200*(4mm) | ||
| Folding hinges | Galvanized hinge 13mm | ||
|
House Top |
Overall Frame Protection Coatings | Electrostatic spray/high-gloss white | |
| External top plate | 0.5mm Galvanized sheet | ||
| Internal ceiling | Color steel veneer V930*0.25㎜ | ||
|
Wall Panel |
Insulation glass wool | Glass wool roll 50mm | |
| Side wall | 50mm composite board 0.23mm+basalt wool+0.23mm | ||
| Front and rear wall panels | 65mm composite board 0.23mm+basalt wool+0.23mm | ||
| Floor | Fireproof glass magnesium floor 15mm | ||
|
Electrical System |
Electrical wiring is installed in strict accordance with moisture-proof specifications, and all electrical products must comply with CE certification. Connect the circuit according to circuit engineering specifications, indoor: 4² national standard soft copper wire, 1 20A circuit breaker, 2.5² incoming socket , 1 five-hole single-opening socket, 1 ten-hole socket, 1 air conditioner socket, 1 lamp indivual. | ||
| Security Door | High quality security door (warm white) size: 930mm*1970mm | ||
| Window | 930*930 plastic steel anti-theft integrated window, glass thickness 4mm (warm white) | ||
| Quality Assured | The whole box as a whole meets the A-level fire protection standard. | ||
How To Expand Our Folding Container House:
It is very easy for expanding our folding container house, just prepare a crane and arrange 2 people, the house will be expanded very soon.
FAQ
Certainly! Here are some frequently asked questions (FAQs) about prefab Folding Container Houses:
How long does it take to assemble a Folding Container House?
A. The assembly time for a Folding Container House depends on factors such as the size of the structure, the complexity of the design, and the number of people involved in the assembly process. On average, it can be assembled within a few days to a couple of weeks.
Q. Are Folding Container Houses durable?
A. Yes, Folding Container Houses are designed to be durable and structurally sound. They are constructed using high-quality materials, such as steel frames and weather-resistant panels, ensuring their durability and ability to withstand various weather conditions.
Q. Can Folding Container Houses be customized?
A. Yes, Folding Container Houses can be customized to suit individual preferences and specific needs. The interior layout, finishes, and amenities can be customized to create personalized living or working spaces.
|
|
